Dixon ZTR 4426 Operator's Manual

4000 SERIES1999 Operator's Manual

Page 10WARRANTY: The Dixon Protection Plus Warranty term is for a period of two (2 ) years from date ofpurchase. DIXON ZTR MOWERS ARE WARRANTE

Page 11SPECIFICATIONSModels ZTR 4423 & ZTR 4426CHASSIS: Twin 12 gauge side frames and 7 gauge transmission and engine base plate.BODY: All body

Page 121. Place parking brake in ON position. (Pull brake lever up)2. Raise and push seat assembly forward.3. Loosen five nuts, P/N 3205, and slide

Page 13CONTROLS

Page 14CONTROLSPARKING BRAKE:The parking brake is designed to hold the mower from movingand is not intended for use in stopping the mower while it is

Page 15CONTROLSTO GO FORWARD:From neutral position, gently push both drive levers forward.To increase speed, move levers farther forward.TO GO BACKWA

Page 16CONTROLSMOWER DECK CUT HEIGHT LIFT LEVER:Located to the left of operator.Controls the cutting height.Seven positions of adjustment.Move lever

Page 17OPERATION INSTRUCTIONSSafe and successful operation will depend upon the operator having the correct knowledge ofall controls used on the mow

Page 18OPERATION INSTRUCTIONSPARKING BRAKE SWITCH TEST:a) Place Parking Brake in OFF positionb) Turn ignition switch to STARTEngine should not turn o

Page 19OPERATION INSTRUCTIONSSTARTING INSTRUCTIONS:1. Parking brake must be on, and blade drivedisengaged.2. Move throttle control to "Choke&quo

The Dixon® ZTR® Mower is both easy and fun to operate. However,any power mower must be operated properly to be safe. It is not a toy or a recreational

Page 20OPERATION INSTRUCTIONSMOWING WITH A MULCHING ATTACHMENT:Mulching or recycling the grass clippings requires a totally different mowing approach

Page 21OPERATION INSTRUCTIONSMOWING WITH A GRASS CATCHER ATTACHMENT:In order to achieve optimum performance when mowing with a grass catching attachm

Page 22OPERATION INSTRUCTIONSSIDE DISCHARGE OF THE CLIPPINGS:In order to achieve optimum performance when side discharging the grass clippings,please

Page 23ENGINE: For engine operating and maintenance information, refer to the engineoperating and maintenance instructions furnished by the engineman

Page 24CUTTER BLADE MAINTENANCE:NOTE: Observe proper blade position prior to removal.1. Safely raise front of mower.2. Hold or block blade from turni

Page 25CARE AND MAINTENANCEBELT TENSIONTRANSAXLE DRIVE BELT: P/N 7650No adjustment required.ENGINE TO MOWER DECK BELT: P/N 7725No adjustment required

Page 26CARE AND MAINTENANCEMOWER DECK LEVELING PROCEDURE:1. Place mower on a smooth, level surface and check tire pressures to insure correct stance.

Page 27DECK REMOVAL:1. Place cut height lever in lowest cut position.2. Pull belt idler back to allow belt to be removed from idler pulley and electr

Page 28CARE AND MAINTENANCECAUTIONHOT oil may cause burns. Allow engine to cool before drainingoil.CHANGING THE ENGINE OIL:1. The "snap lock&

Page 291. Push the valve body in and twist into the detent notch.2. Clean any spilled oil from engine and chassis.3. Refill engine with type, and qu

Page 3INDEXSAFETY... Pages 2 - 7WARRANTY POLICY ...

Page 30DRIVE SYSTEM ADJUSTMENTS:Due to both the complex nature of the transmission and the number of special tools requiredfor service, adjustments s

Page 31CARE AND MAINTENANCEWHEELS AND TIRES:Correct tire pressure is important for correct operation of mower.Front Tires 11 X 4.00 X 5 16-21 lbs. P

Page 32STANDARD SERVICE PARTS LISTBLADES: Lo-Lift: P/N 6236Standard Hi-Lift: P/N 8688BELTS: Engine To Mower Deck: P/N 7725Serpentine Belt: P/

Page 33SITUATION CAUSES REMEDYPoor cut quality Ground speed too fast Reduce mowing speedPoor cut quality Incorrect engine to Install correct belt P/N

Page 34SITUATION CAUSES REMEDYMower pulls to one Drive adjustment Consult your dealer for repairside or the otherPoor driving Operation of mower Revi

Page 35ELECTRICAL SYSTEM:SITUATION CAUSES REMEDYStarter will not Circuit breaker Push button to resetturn engine over disengaged Consult your dealer

Page 36NOTES

Page 37NOTES

DATE PURCHASEDMOWER MODEL NUMBERMOWER SERIAL NUMBERPURCHASED FROMOWNERINFORMATIONDATE OIL CHANGED: DATE ENGINE TUNED:DM-AddressNameDIXON INDUSTRIES

Dixon® and ZTR® are registered trademarks of Dixon Industries, Inc.4000SeriesPart No. 8950-0598DIXON INDUSTRIES, INC.A BLOUNT International Inc. Co.P

Page 4RIDING LAWNMOWERS, IF IMPROPERLY OPERATED,CAN CAUSE SERIOUS INJURY OR DEATHThe most common causes of injury to the operator or bystander...r

Page 5SAFETY SYSAFETY SYSAFETY SYSAFETY SYSAFETY SYMMMMMBOLSBOLSBOLSBOLSBOLSCautionindicates a potentially hazardous situationwhich, if not avoided,

Page 6GENERAL OPERATION:• Read, understand, and follow all instructions in the manual and on the mower beforestarting.• Only allow responsible adults

Page 7DOMow across the slope with your Dixon ZTR - never up or down.Remove obstacles such as rocks, tree limbs, etc.Watch for holes, ruts or bumps.

Page 8Tragic accidents can occur if the operator is not alert to thepresence of children.Children are attracted to lawn mowers and the mowing activit

Page 9SERVICE: • Use extra care in handling gasoline and other fuels. They are flammable and vaporsare explosive.Use only an approved container.Neve
